- SLD
- China
- 10 DAYS
- 10,000,000 M2/year
• ISO 5, FED: Class 100
• Dura-Washable,Scrubbable,Soil-resistant
• Non-direction pattern design saves installation time
• Excellent light reflectance
• Excellent sound absorption
• 100% free from asbestos
HEALTHGUARDER Clean room Ceiling Tile
Technical Data*18mm
Specification Item | Data |
Raw materials | Wet-formed mineral fiber |
| Surface finish | Soil-resistant polyester film |
NRC | up to 0.55 |
HR | up to RH99 |
Fire resistance: | Class A (GB8625-88) |
CAC | 40 |
Density | 260-280kgs/m3 |
Moisture rate (%): | ≤3 |
Light reflect | 86 |
Bending strength(N) | ≥60 |
Standard Size*
Metric Dimension | Imperial Dimension | DIN Dimension | |||
Nominal (mm) | Actual(mm) | Nominal | Actual(mm) | Nominal (mm) | Actual(mm) |
600x600 | 595x595 | 2'X2' | 605x605 | 630x630 | 625x625 |
600x1200 | 595x1195 | 2x4' | 605x1215 | 630x1260 | 625x1250 |
*Plank sizes are available
Thickness (from 14mm to 18mm )*
Qty./box | Weight/box | |||
width(mm) | length(mm) | thickness(mm) | pcs | kgs |
595/605 | 595/605 | 14 | 14 | 19.0 |
16 | 12 | 18.7 | ||
18 | 10 | 17.5 | ||
595/605 | 1195/1215 | 14 | 10 | 27.2 |
16 | 31.1 | |||
18 | 8 | 28.0 | ||
Edges
Installation
Typical Application Areas
· Hospitals and other Public Site
· Offices and conference rooms
· Laboratory
· Education
· Healthcare
